Sleeps 4
-
3 Slides
-
Rear Living AreaKitchen Island
-
41ft Long
-
14,270 lbs
-
MODERN FARMHOUSE
38KPTS Floorplan
Specifications
Sleeps | 4 | Slides | 3 |
Length | 41 ft 1 in | Ext Width | 8 ft 6 in |
Ext Height | 13 ft 4 in | Int Height | 8 ft 6 in |
Interior Color | MODERN FARMHOUSE | Exterior Color | SILVER METALLIC |
Hitch Weight | 2780 lbs | GVWR | 16995 lbs |
Dry Weight | 14270 lbs | Cargo Capacity | 3080 lbs |
Fresh Water Capacity | 75 gals | Grey Water Capacity | 87 gals |
Black Water Capacity | 50 gals | Tire Size | 215/75R17.5"H |
Furnace BTU | 40000 btu | Available Beds | King |
Refrigerator Type | Residential | Refrigerator Size | 21 cu ft |
Convection Cooking | Yes | Cooktop Burners | 4 |
Number of Awnings | 2 | LP Tank Capacity | 40 lbs. |
Water Heater Capacity | 16 gal | Water Heater Type | Gas/Electric DSI |
AC BTU | 30000 btu | TV Info | LR 50" Smart LED HDTV, BR & EXT 32" 4K Smart LED TV |
Awning Info | 11' and 17' Electric with LED Lights | Axle Count | 2 |
Washer/Dryer Available | Yes | Number of LP Tanks | 3 |
Shower Type | Walk-In Shower | Electrical Service | 50 amp |
VIN | 1UJCF0BV6S1RG0050 |
Description
Jayco Pinnacle fifth wheel 36KPTS highlights:
- Dishwasher
- 32" Bedroom TV
- Free-Standing Table
- Flip-Up Dresser
- King Bed Slide Out
- Shoe Garage
Your search is over now with this perfect luxury fifth wheel for your crew of four. Once you get settled at the campground, take a load off on the theater seat across from the TV lift and fireplace. There is also a free-standing table here and a tri-fold sofa that will double as additional seating and sleeping space. The kitchen island includes a pull-out butcher block extension for tons of prep space and even a dishwasher for easy clean up, and a residential 24" range to use for cooking as well as a convection microwave oven with built-in air fryer. Head to the full bath that includes a walk-in shower with a seat, an LED backlit custom framed mirror, plus residential bath backsplash for added luxury. You're gong to love the front private bedroom with its king bed slide out, 32" TV, plus a large front closet complete with a hamper and drawers, and an area that features washer/dryer prep in case you wish to add that convenience as well.
Each Pinnacle fifth wheel features Stronghold VBL lamination for the lightest, yet strongest construction in the RV industry. Add that to the Magnum Truss XL6 roof system and Climate Shield zero-degree tested weather protection and you'll be enjoying your fifth wheel for years to come. Some of the exterior conveniences you will appreciate are the Keyed-Alike lock system, the fully enclosed, universal docking center, and the 6-point hydraulic auto-leveling system for quick and easy set up. The 5 Star Handling Package will make towing a fifth wheel a walk in the park, and the two Whisper Quiet A/C units will keep you comfortable during the hot summer months. Inside, you'll enjoy the farmhouse stainless steel sink, the handcrafted hardwood glazed cabinetry, the vinyl flooring throughout, plus many more comforts. There is even a central vacuum system, a wireless remote control system, USB ports throughout, plus many more conveniences to make each trip enjoyable.
- 15K WHISPER QUIET AIR BEDROOM
- 15K WHISPER QUIET AIR W/HEAT PUMP (LIVING ROOM)
- 16 GALLON LP/110 WATER HEATER W/DSI
- 17.5" 16 PLY H RATED UNIROYAL TIRES
- 1800 WATT INVERTER FOR REFRIGERATOR
- 2 BATTERIES
- 2 YEAR MANUFACTURER LIMITED WARRANTY
- 21CU FT RESIDENTIAL REFRIGERATOR
- 2ND ELECTRIC PATIO AWNING W/INTEGRATED RGB LIGHTS
- 3 YEAR MANUFACTURER LIMITED STRUCTURAL WARRANTY
- 32" 4K LED SMART TV IN BEDROOM
- 32" EXTERIOR 4K LED SMART TV
- 3RD AIR IN LIVING AREA - 15K
- 5-STAR HANDLING PACKAGE
- 50" 4K SMART LED TV W/FULLY DIGITAL HDMI
- 6 POINT HYDRAULIC LEVELING SYSTEM
- AWNING TOPPER(S) SLIDE-OUTS
- BACK-UP/SIDE/ENTRY DOOR OBSERVATION CAMERA PREP
- BACK-UP/SIDE/ENTRY OBSERVATION CAMERAS
- BRONZE BUSHINGS/4000# LEAF SPRINGS
- CELLULAR PREP FOR 5G WIFI ANTENNA/JAYCOMMAND
- CENTRAL VACUUM SYSTEM W/DUST PORT
- CONVECTION MICROWAVE W/BUILT-IN AIR FRYER
- CUSTOM MACHINED ALUMINUM WHEELS
- CUSTOMER SCHOOLING
- CUSTOMER VALUE PACKAGE
- DAY/NIGHT ROLLER SHADES IN LIVINGROOM
- DEXTER AXLES W/ABS/TOW ASSIST/NEV-R-ADJUST BRAKES/EZ LUBE HUBS
- DO IT ALL KITCHEN SINK
- DOVETAIL JOINTED DRAWERS
- ELECTRIC PATIO AWNING W/INTEGRATED RGB LIGHTS
- EQUIPMENT MAY CHANGE/VARY DUE TO 2025 MODEL CHANGES
- FILL LPG
- FRAMELESS DARK TINTED SAFETY GLASS WINDOWS
- FREESTANDING ROLL TOP TABLE W/2 FS CHAIRS & 2 FOLDING CHAIRS
- FULL BODY PAINT OPTION
- GE PROFILE 24" RESIDENTIAL RANGE
- GENERATOR PREP - LP
- HIDDEN HINGES W/MAGNETS/SOFT CLOSE CABINET DOORS
- HIGH GLOSS GEL-COATED SIDEWALLS
- JAYCOMMAND "SMART RV" SYSTEM
- JBL HOME ENTERTAINMENT SYSTEM W/SOUNDBAR/SUBWOOFER
- KEYED-A-LIKE LOCK SYSTEM
- LED FIREPLACE W/ELECTRIC SPACE HEATER
- MORRYDE LRE-4000 RUBBERIZED SUSPENSION
- MORRYDE RUBBER PINBOX
- MORRYDE SAFE-T-RAIL GRAB HANDLE
- MORRYDE STEPABOVE ENTRANCE STEPS (MAIN DOOR) W/STRUT ASSIST
- NUVO WATER DRINKING SYSTEM W/3 CARTRIDGES
- OVERLANDER II SOLAR PACKAGE
- OVERSIZED MULTI BATTERY COMPARTMENT
- PINNACLE LUXURY PACKAGE
- POWERED 50AMP CORD REEL
- PRE-DELIVERY INSPECTION
- RESIDENTIAL KING BED (72" X 80") MATTRESS W/UNDERBED STORAGE
- RESIDENTIAL SOLID SURFACE KITCHEN COUNTERTOP
- RESIDENTIAL WALK-IN SHOWER
- ROOF/GROUND SOLAR PREP
- SANICON DUMP SYSTEM
- SHAMPOO/SOAP HOLDER IN SHOWER
- SOLID HARDWOOD DOORS/CABINET STILES
- TEAK SEAT AND SHOWER TOWER
- TRAILER PAC VOUCHER
- UNDERSINK DISHWASHER
- WASHER DRYER PREP
- WATER SOFTENING AT KIT SINK/WATER/ICE DISPENSERS IN RESIDENTIAL REFRIGERATOR
- WET BOLT FASTENERS
- WIRELESS REMOTE SYSTEM
Features
Standard Features (2025)
Exterior Equipment
- (3) 40 lb. LP propane bottles with auto regulator (120 lb. max LP system)
- 102 in. widebody construction
- 12 in. structural steel I-beam with 10 in. steel drop frame
- 120V heat blankets on all tanks plus 12V heat tape on fresh water line
- 3,000 lb. tow hitch with 4-way pin
- Battery disconnect
- Built in sewer hose carrier
- Climate Shield™ zero-degree tested weather protection:
- 40,000 BTU output furnace
- Double layer fiberglass batt insulation (roof and floor)
- Fully enclosed and heated underbelly (ducted)
- PEX plumbing, 2 in. block foam and reflective foil
- Custom automotive-grade vinyl exterior graphics package
- Digital TV antenna with 5G Wi-Fi extender
- Exterior marine-grade speakers with Bluetooth® controller
- Frameless dark tinted safety-glass windows
- Fully enclosed, universal docking center:
- Black tank flush
- Independent satellite wiring
- Quick-connect outside shower
- Selectable water connections
- Whole coach cable hookups
- Winterization and sanitation hookups
- Inverter pre-wire to select outlets
- JayPort outside griddle prep (standard on all floorplans without a standard outside kitchen)
- JaySMART™ (Safety Markers And Reverse Travel) LED lighting (patented)
- LED exterior lighting package
- Magnum Truss™ XL6™ Roof System (strongest tested roof in the industry) with Alpha roof membrane system with limited lifetime warranty
- Painted fiberglass front and rear cap with clear coat and built-in specialty LED lighting
- Pass-through storage with Slam-latch™ baggage doors
- Skirt metal enclosed drop frame
- Stronghold VBL™ aluminum framed and vacuum bond laminated gel coated fiberglass exterior walls (including slide room end walls)
- Under-mounted spare tire
- Water heater bypass
Standard Interior Equipment
- 12V charging station
- 5/8 in. tongue-and-groove joined plywood floor and 3/8 in. plywood roof decking
- Bathroom skylight
- Built in spice rack in kitchen cabinet (select models)
- Built-in laundry hamper in wardrobe (select models)
- Carbon monoxide and LP detector
- Cedar-lined front wardrobe closet
- Ceiling fan (select models)
- CPAP prepped bedroom
- Extra 120V power outlets in kitchen and slide rooms
- Flip-up countertop extension/bar top (select models)
- Flip-up hidden storage in bedroom chest of drawers (select models)
- Flip-up tabletop storage next to tri-fold sofa (select models)
- Gas-strutted under-bed storage
- Handcrafted hardwood glazed doors, stiles, drawers and trim
- Hidden hinges, magnet latches and soft close cabinet doors and drawers
- Integrated under-mount sink and lever faucet in main bathroom
- LED accent lighting above slideouts
- LED backlit custom framed mirror and medicine cabinet (most models)
- LED interior lighting throughout
- No in floor heat ducts throughout coach
- Pantry with adjustable shelves and pull out drawers includes 120V outlet (most models)
- Porcelain toilet with foot flush
- Removable tray tables at theater seats
- Residential "Do it all" sink with pull-out kitchen faucet, glass rinse, and vegetable rinse
- Residential dove tail jointed drawers throughout
- Residential NuVo H2O whole coach water treatment system with water softening and triple cartridge filters
- Residential quilted bedspread and pillows
- “Shoe garage” in hallway step (select models)
- Soft close, heavy-duty, 75 lb. full extension, steel ball-bearing drawer guides
- Solid hardwood slide fascia
- Stain protected fabric on all furniture
- Toe kick nightlights in bedroom, bathroom and kitchen
- Tri-fold hide-a-bed sofa with sleep surface (select models)
- Vinyl flooring (made in the USA) throughout including slide rooms
Customer Value Package (Mandatory)
- 15,000 BTU “Whisper Quiet” A/C (bedroom)
- 15,000 BTU “Whisper Quiet” A/C with heat pump (main)
- 16 gal. gas/electric DSI water heater
- 50 in. 4K SMART LED HDTV with fully digital HDMI® output and two additional HDMI® cables
- Backup, main entrance door and side observation security camera prep (includes a power switch in the bedroom to use the optional 7 in. monitor for security)
- Custom machined aluminum rims
- Electric patio awning with integrated RGB LED lights (multi-colored with remote control)
- Hidden hinges, magnet latches, and soft close cabinet doors
- JBL® home entertainment system with sound bar and wireless subwoofer
- Keyed-Alike™ lock system (single key for all doors/locks)
- MORryde Safe-T-Rail grab handle
- Residential king (72 in. x 80 in.) mattress with under-bed storage
- Rooftop and ground solar prep
- Wireless remote control system (includes Bluetooth® wireless interior controls) with dimmer switches
5 Star Handling Package (Mandatory)
- 5 in. 16 ply 'H' rated Uniroyal tires
- Dexter® Axles with ABS and Tow Assist - includes Nev-R-Adjust® brakes and E-Z Lube® hubs
- MORryde® LRE-4000™ rubberized suspension
- MORryde® rubber pin box
- Wet bolt fasteners, bronze bushings and 4,000 lb. leaf springs
Luxury Package (Mandatory)
- 2nd electric patio awning with integrated RGB LED lights (multi-colored with remote control)
- 32 in. 4K outside Smart LED TV
- 32 in. 4K Smart LED bedroom TV
- 6-point hydraulic auto-leveling system
- Cellular prep for 5G Wi-Fi antenna and JAYCOMMAND®
- Central vacuum system with dust port
- Day/night roller shades in living room
- Frameless dark tinted safety-glass windows
- Free-standing roll top (no pedestal) table with (2) free-standing and (2) folding chairs
- GE 21 cu. ft. residential refrigerator with 1800W inverter
- GE Profile Series 30 in. residential convection microwave with built in air fryer
- GE Profile Series residential 24 in. range (3.7 cu. ft. with 9100 BTU high output burner)
- High gloss gel coated sidewalls
- JAYCOMMAND® Smart RV System
- LED fireplace with electric space heater
- MORryde® StepAbove™ entrance steps (main entrance) with strut assist
- Oversized multi-battery compartment (industry leading room for 4-6 batteries)
- Powered 50-amp cord reel
- Residential solid-surface kitchen countertop
- Residential walk-in shower with shampoo/soap holder, teak seat and shower tower
- Solid hardwood cabinet doors, stiles, and fascia
- Under-sink dishwasher
- Washer/dryer prep
- Pull out "Roll Top" dinette with two free standing chairs and two folding chairs
- Residential NuVo H2O whole coach water treatment with water softening system and triple cartridge filters
Options
- 20 cu. ft. 12V refrigerator
- 3rd 15,000 BTU ducted A/C
- 5,500W Onan® Microquiet generator
- 7K hydraulic disc brake package (ABS N/A with disc brakes)
- 8K hydraulic disc brake package (ABS N/A with disc brakes)
- Butler’s pantry (in place of half bath 38FLGS)
- Frameless dual-pane tinted safety-glass windows
- Front wardrobe in place of front windshield and sofa lounge (36SSWS)
- Full body paint- Midnight Gold, Silver Metallic, Midnight Charcoal
- Generator prep
- MORryde independent suspension and shocks with 8K axles and disc brakes (ABS not available)
- Outside Halo griddle for JayPort system or outside kitchens includes LP quick connect (select models)
- Overlander 2 Solar Package: 30-amp controller, (1) 1800W inverter and (2) 200W solar panels
- Overlander 4 Solar Package: (4) 200W solar panels, (2) 100-amp/hour lithium heated batteries, 60-amp controller, 3000W inverter, DC/DC power converter, soft start power save main 15K A/C, soft start power save for bedroom 15K A/C, battery monitor, energy management system, roof pre-wire for additional solar panels, generator prep capable and heavy gauge steel battery enclosure
- Overlander EXT Solar Package: 3,000W inverter/charger with internal 50-amp transfer switch, energy management system, (6) solar panels with 200W each, (6) 100-amp/hour lithium heated batteries, 12V DC A/C in bedroom, DC to DC battery charger, 100-amp MPPT controller management, generator prep capable
- Queen residential foam-top mattress
- Sani-Con® Turbo waste management system
- Slideout awning(s) (quantity varies by model)
- True interior design choice (Modern Farmhouse or Vintage Farmhouse)
- Truma on-demand hot water system
- Wireless backup/side view/front entry door observation kit with 7 in. monitor
See us for a complete list of features and available options!
All standard features and specifications are subject to change.
All warranty info is typically reserved for new units and is subject to specific terms and conditions. See us for more details.
Due to the current environment, our features and options are subject to change due to material availability.
Save your favorite RVs as you browse. Begin with this one!
-
Excellent Customer Service
I’ve been looking for the right solution for a long time for my towing and recreational vehicle needs and when I came across the Johnny Walker ad for the Thor SV 34 and the awesome price that they had on it. I couldn’t resist diving into it, well a week later I purchase this beautiful 4 x 4 powered -
Excellent Customer Service
We had a great experience! Everyone was friendly and knowledgeable. Made the process very easy. Thank you! -
Excellent Customer Service
We purchased an RV at the end of January. We went to a couple places to look for an RV that would fit my family of 5. As soon as we walked in JWRV, we were immediately greeted with warm friendly smiles and amazing customer service. The other place we visited that day was dirty, bad customer service,
Loading
Johnnie Walker RV Sales is not responsible for any misprints, typos, or errors found in our website pages. Any price listed excludes sales tax, registration tags, and delivery fees. Manufacturer pictures, specifications, and features may be used in place of actual units on our lot. Please contact us @725-242-8773 for availability as our inventory changes rapidly. All calculated payments are an estimate only and do not constitute a commitment that financing or a specific interest rate or term is available.
Manufacturer and/or stock photographs may be used and may not be representative of the particular unit being viewed. Where an image has a stock image indicator, please confirm specific unit details with your dealer representative.
